Fischbein 100/101

Fischbein 100/101 Spare Parts
ImageItemShort descriptionCategories
Item
Short description
Categories
Item
Short description
Categories
1-178Nut, lock
A-10004Lever, presser foot
A-10005Door , looper
A-10007Sprinf::i. tension needle thread
A-10008Spring, tension looper thread
A-10009Spring, tension (needle lever)
A-10011Screw, clamp needle
A-10014Plate, cover - top
A-10015Post, short-throat plate
A-10016Post, long - throat plate
A-10017Throat plate
A-10023Insert, thread - lever shaft bushinq
A-10025Bushing, shaft levers
A-10026Shaft, lever
A-10029Bushing, lever presser foot
A-10031Chuck needle
A-10035Assembly, seal mainshaft
A-10038Hub, pulley
A-10048Retainer, rod connectinQ
A-10052Washer, Nylon
A-10056BushinQ, Shaft Looper
A-10059Holder, Looper
A-10060Looper
A-10067Nut, pivot feed stroke
A-10068Pivot, adjustinq feed stroke
A-10073Slide feed
A-100750-ring
A-10077Seal, dog feed
A-10078DoQ feed
A-10080Assembly, connecting rod knife
A-10082Crank, bell knife
A-10083Shaft, bell crank knife
A-100840-ring
A-10085Bracket, pivot knife
A-10086Link, knife
A-10087Screw, pivot knife
A-10089Sprinq knife
A-10092Gasket, Cover-Top
A-10093Gasket, cover - bottom
A-10094Gasket, mainshaft seal
A-10095Gasket, cover - manifold
A-10098Cover, groove - thread
A-10109Bushinq, shaft feed rocker
A-10111Plug, drain - magnetic
A-10112Window, oil level
A-10113Stud, tension (needle lever)
A-10114Sleeve, tension
A-10114Sleeve, tension
A-10115Stud, tension
A-10116Assy, plug - breather
A-10119Disc, tension (needle lever)
A-10119Disc, tension (needle lever)
A-10120Disc, tension larqe
A-10124Ring, Garter-Seal (Feed Dog)
A-10125Pluq, pipe ma1nshaft
A-10128Spring, garter lever seal
A-10139BushinQ, lifter presser foot
A-10142Cam, lifter presser foot
A-10143Shaft, Sprinq Presser Foot
A-10144Clamp, spring presser foot
A-10145Sprinq, presser foot
A-10146Plate, presser foot
A-10153Knuckle, Pivot Looper
A-10155Shank, presser foot
A-10156Block, h1nqed presser foot
A-10157Assembly, presser foot
A-10161Guide, lever presser foot
A-10161Guide, lever presser foot
A-10162Sheet, bearinQ presser foot
A-10163Clamp, bearing sheet
A-10164Eyelet, thread short
A-10165Eyelet, thread long (Guide)
A-10166Guide, thread (needle lever)
A-10170Pull off looper thread
A-10171Pull off, needle thread
A-10171Pull off, needle thread
A-10173Assembly, Pivot Looper
A-10174Guard, needle
A-10177Holder, guard needle
A-10182Bolt, hinqinq presser foot
A-10185Presser foot
A-10186Liner, bushing lifter presser foot
A-10187Spring, lifter lever
A-10188Guard, tension needle
A-10189Cradle, pad presser foot
A-10190Pad, sprinQ presser foot
A-10199Pulley, adjustable assembly
A-10211Plug, clam drilled
A-10211Pluq, clam drilled
A-10212Plug, clamp tapped
A-10213Pluq, clamp drilled (presser foot)
A-10214Plug, clamp tapped (presser foot)
A-10215Washer, Thrust
A-10216Eyelet, Rip Cord
A-10234Washer, Sorinq
A-103380-ring, 7/8 ID
A-10398Ring, Backup
A-10399U-Cup
A-10403Assembly, Seal-Shaft
A-10404Assembly, Crank
A-10406Washer, Head Cylinder
A-10407Plate, Bumper
A-10408RinQ, Bumper
A-104090-rinq, Cylinder Head
A-10410Head, Cylinder
A-10411Ring, Snap
A-10419Crankshaft
A-104200-rinq-Crankshaft
A-10424SprinQ, Compression
A-10426Shaft, Knife
A-10427Shaft, Thrust
A-10428Washer, Thrust
A-10429Gasket
A-10430Plate, Cover
A-10432Lever, Knife
A-10434Post-Offset
A-10438Washer, Compression
A-10440Screw, Adjusting
A-104410-ring, 5/8 ID
A-10442Plug
A-10443Knife, Moving
A-10446Knife, Blade-Bed (wide)
A-10447Assembly, Lever Cutter
A-10449Fence, Throat
A-10458Assembly, Piston-Tape Clipper
A-10481Assembly, Presser Foot, Tape (wide)
A-10484Presser foot, Tape (wide)
A-10485Throat plate, Wide Tape (STD)
A-10486DoQ, feed, Tape (STD)
A-10721Sprinq, tension-liqht needle thread
A-11120Washer, Lock
A-11268Nut, lock
A-11309Nut, Hex 10-32
A-15015Mount Pump
A-15024Spacer, Shim
A-150320-ring
A-15039Pin, Pivot Looper
A-15043Collar, lock mainshaft
A-15053Gauge, oil pressure 60 PSI
A-15054Cartridge, oil - filter
A-15056Manifold, filter Assy.
A-15059Fittinq
A-15062Nipple , filter oil
A-15064Plug, ad?vusting - manifold
A-15065Clamp
A-15066WASHER, THRUST-.312 ID X .750
A-15069Ball , chrome (part of Item 36 (15056) assy)
A-15072Cover, bottom
A-15074Seal, Pressure Control-Manifold
A-15076Washer, Spnnri ?
A-15078Spring, pressure (part of Item 36 (15056) assy)
A-15079Plate, cover - side
A-15088Tubing, copper
A-15104Assembly, Seal, Knife Shaft
A-15105Gasket, Looper Shaft Seal
A-15108Screw
A-15109Screw, Soc. Set Cone Point??/4-20 X 3/8
A-16034Fitting, Adapter 1/8 M x 1/8 F 45 Deg
A-16035CORDGRIP, 1/2NPT
A-16291DWG, PNEU SCHEM STD NEEDLE COOLER
A-31 1 1 1SHAFT, MOVABLE KNIFE
A-31002Housing, main
A-31004Eccentric, stroke feed
A-31005Lever, pin feed rocker
A-31006Pin, rod feed stroke connect.
A-31007Lever, slotted feed rocker
A-31008Clamp, rod feed doq carrier
A-31009Link, lift feed
A-31010Link, stroke feed
A-31011Rod, carrier feed dog
A-31012Rod, slide feed
A-31013Shaft, Looper
A-31014Seal, levers
A-31015Shaft, main
A-31016Shaft, knife
A-31018Assembly Cam, Looper
A-31020Rod, connecting needle drive
A-31021Bushing, mainshaft drive end
A-31022Bushing, ma1nshaft needle end
A-31023Rod, connecting prim. Feed stroke
A-31024Lever, needle
A-31028Gear, drive pump
A-31029Moving knife
A-31031Cover, guard lever
A-31032Stationary knife
A-31033Housing, levers (LT Blue)
A-31034Lever, lifter presser foot
A-31035Assy, Clipper
A-31036Housing, Cutter
A-31037PLATE, THROAT (STD) LO-SP
A-31038PLATE, THROAT (LONG STITCH) LO-SP
A-31042Washer, Thrust (special)
A-31043Bracket, Oil Line (Plastic)
A-31045Fitting
A-31096Assembly, Gear Pump (Modified)
A-31101KIT, AIR CYLINDER ASSY
A-31103HUB, MOVABLE KNIFE MOUNTING
A-31104LEVER, AIR CYLINDER DRIVE
A-31105HUB, DRIVESHAFT SUPPORT
A-31106PIN, AIR CYLINDER PIVOT
A-31108BRACKET, UPPER FIXED BLADE
A-31109BRACKET, LOWER FIXED BLADE
A-31110BLOCK, MOUNTING
A-31111SHAFT, MOVABLE KNIFE
A-31112BLADE, MOVABLE KNIFE
A-31113BLADE, FIXED KNIFE
A-31115COVER, SIDE
A-31116PLATE, THROAT (STD) HI-SP
A-31117BEARING, DU FLANGED
A-31120E-RING, CIRCLIP D8
A-31122SPRING, COMPRESSION
A-31123BLOCK, MOUNTING THROAT PLATE
A-31124PLATE, THROAT (LONG STITCH) HI-SP
A-31128KIT, SOLENIOD
A-31129TUBING, POL YURETHENE, GREEN, 6mm
A-31131PLATE, SUPPORT
A-31132COVER
A-31148LABEL, VOLTAGE (24 VDC)
A-31156GUIDE, AIR KNIFE BAG
A-31158LABEL, VOLTAGE (110 V)
A-31162KIT, SOLENIOD, 24VDC
A-67735Tubinq
A1882Bushing, Neoprene
A3934Washer, Thrust
B103214Screw, bindinQ HD 10-32 x ??/4
B103238Screw, Bindinq HD 10-32 x 3/8
B632316Screw, Binding HD 6-32 x 3/16
C100-SNeedle
F103212Screw, Flat 10-32 x !/2
F103238Screw, Flat 10-32 x 3/8
F103258Screw, Flat 10-32 x 5/8
F54038Screw, Flat 5-40 x 3/8
F63214Screw, Flat 6-32 x !/4
F83212Screw, Flat 8-32 x !/2
F83214Screw, Flat 8-32 x 1/4
H 103234Screw, Hex HD 10-32 x ?
H103212Screw, Hex HD 10-32 x ;/2
H103234Screw, Hex 10-32 x ?
H103258Screw, Hex 10-32 x 5/8
H103278Screw, Hex HD #10-32 x 7/8
H142812Bolt, Hex 1/4-28 x !/2
H3824134Screw, Adj. 3/8-24 x 1 ?
NH1420Nut, Hex 1/4-20
NH1428Nut
NH1428LNut 1/4-28 locking
NH832Nut, Hex #8-32
P4024Bearing, Thrust
P4139SEAL, MOISTURE (1/2")
P4943Fittinq, Nipple Short
P4944Fitting, Nipple Long
P4957Fitting, Elbow Street
P4962FittinQ, Elbow Female
P540916Screw, Pan HD 5-40 x 9/16
PHM258SCREW, PAN HD M2.5 X 8mm
PS141Pin, Spring
PS14112Pin, Spnnq
PS18114Pin, Spnnq retaininq tension disc
S8103212Screw, Soc. BTTN #10-32 x !/2
S8103214Screw
S8142014Screw, Soc. Set 1/4-20 x 1/4
SB103212Screw, Soc. BTTN 10-32 x !/2
SBM510SCREW, SOC BUTTON M5 X 10mm
SC103212Screw, Soc. Cap #10-32 x ;/2
SC103234Screw, Soc. Cap 10-32 x ?
SC103238SCREW, SOC CAP #10-32 UNF X 3/8
SC103258Screw, Soc. Cap 10-32 x 5/8
SC103278Screw, Soc. Cap 10-32 x 7/8
SC14201Screw, Soc. Cap 1/4-20 x 1
SC14201Screw, Soc. Cap !/4-20 x 1 Locking
SC1420114Screw, Soc. Cap 1/4-20 x 1 !/4
SC142034Screw, Soc. Cap 1/4-20 x ?
SC142078Screw, Soc. Cap 1/4-20 x 7/8
SC142878Screw, Soc. Cap 1/4-28 x 7/8
SC516181Screw, Soc. Cap 5/16-18 x 1
SC5161858Screw, Soc. Cap 5/ 16-18 x 5/8
SC54012Screw
SC63234Screw, Soc. Cap 6-32 x ?
SCM1022SCREW, HEX M10 X 22mm
SCM618SCREW, SOC CAP M6 X 18mm
SCM825SCREW, SOC CAP MB X 25mm
SF103238Screw, Soc. Flat 10-32 x 3/8
SF103258Screw, Soc. Flat 10-32 x 5/8
SF54038Screw, Flat 5-40 x 3/8
SFM412SCREW, SOC FLAT M4 X 12mm
SFM416SCREW, SOC FLAT M4 X 16mm
SFM48SCREW, SOC FLAT M4 X 8mm
SFM510SCREW, SOC FLAT M5 X 10mm
SS10321Screw, Soc Set 10-32 x 1
SS103212Screw, Soc. Set 10-32 x)/2
SS103214CPScrew
SS1032316Screw, Soc. Set 10-32 x 3/16
SS1032516Screw, Soc. Set 10-32 x 5/16
SS103258Screw, Soc. Set 10-32 x 5/8
SS103258CPScrew, Soc. Set Cone Point 10-32 x 5/8
SS142014Screw, Soc. Set 1/4-20 x ??/4
SS142038Screw, Soc. Set 1/4-20 x 3/8
SS1O321Screw, Soc. Set 10-32 x 1
SS1O32316Screw, Soc. Set 10-32 x 3/16
SS1O32516Screw, Soc. Set 10-32 x 5/16
SS540316Screw, Soc. Set #5-40 x 3/16
SS832316Screw, Soc. Set #8-32 x 3/16
SS832316CPScrew, Soc. Set 8-32 x 3/16 cone point
SSM46SCREW, SOC SET M4 X 6mm
T3129Washer, Thrust
T3192KEY, WOODDRUFF
WF10WASHER, FLAT #10
WF14Washer, Flat!/4
WF38Washer, Flat 3/8
WF5Washer, Flat 5
WF8Washer, Flat# 8
WFM10WASHER, FLAT M10
WFM12WASHER, FLAT M12
WFM6WASHER, FLAT M6
WFM8WASHER, FLAT M8
WL10WASHER, LOCK #10
WN10Washer, Nylon
WS10Washer, SprinQ 10
